Nestbare Stahlregale für Isolierglas-Einheiten (IGU)

The “Space War” in Glass Fabrication Shops

In a busy glass fabrication shop
, floor space is the most expensive resource. When your
L-Shape Glass Holding Rack fleet is empty, rigid structures become obstacles. They block forklift lanes, crowd the
glass cutting table area, and force your team to waste hours shuffling steel just to access raw
Floatglasscheiben.

Unlike static A-frames that demand dedicated square footage whether full or empty, our nestable design acknowledges the reality of your workflow. When the glass is delivered to the
Verglasungsunternehmen or the construction site, the empty racks must return.

Empty racks aligned against the wall release up to 30% more aisle space for your team.

Protecting High-Value IGUs and Low-E Coatings

Shipping Isolierglaseinheiten (IGU) or Verbundglassätze requires more than just a strong frame; it requires surface integrity. A common failure point in generic racks is the rubber padding. Traditional glued pads degrade under UV exposure or shear off when heavy
1/4 Zoll ESG-Glas is slid into place. Once the metal is exposed, you risk edge chipping or, worse, deep scratches on soft-coat Low-E surfaces.

Unsere Lösung verwendet ein steel-core rubber profile
This isn’t a sticker; it is a mechanical component secured with self-tapping screws directly into the Q235 steel structural tubing
The internal steel plate within the rubber distributes the pressure of heavy loads (up to 4,000 lbs), ensuring the rubber never compresses to the point of metal-on-glass contact. This is critical for preventing seal failure in IGUs caused by transport vibration.

Steel-core rubber profiles secured with screws prevent the “slide-and-tear” damage common with glued pads.

The Economics of Return Logistics

If you are a
glass distributor
shipping from Los Angeles to Sacramento, or supplying
shower door manufacturers
across state lines, freight cost is your enemy. Sending a flatbed truck to retrieve 20 empty A-frames is financial suicide.

Unser rückführbare Versandgestelle utilize a specific geometric base design that allows them to stack horizontally (nesting) like shopping carts or stack vertically when inverted. You can fit approximately 98 to 112 empty units in a single 40HQ container. This density drastically reduces your “cost per trip” for asset recovery, making the closed-loop logistics model actually profitable.

Nesting capability turns a truckload of air into a dense, efficient return shipment.

Designed for the IGU Workflow

Handhabung Isolierglas- or heavy commercial glass
units demands stability. Our racks feature a 90-degree vertical support with a calculated 3-5 degree tilt. This angle is critical: it keeps the glass sheets stable against the backboard without creating excessive lateral stress that could delaminate fresh IGU seals.

Compatible with overhead cranes (via lifting lugs) and standard forklifts, these racks integrate seamlessly from the sealing line to the delivery truck. Whether you are moving
custom shower enclosures
or standard window units, the versatility of the L-shape design accommodates various widths without the footprint penalty of an A-frame.

Ideal for mixed loads of Insulated Glass Units, keeping seals intact during transport.

Frequently Asked Questions (FAQs)

Can these racks hold heavy jumbo architectural glass?
Yes. Our standard Heavy-duty Glass Rack is engineered using Q235 steel with a working load limit (WLL) ranging from 3,000 lbs to 8,800 lbs depending on the configuration. For jumbo sheets, we reinforce the base channels to prevent deflection.

Will the rubber strips leave marks on my Low-E glass?
No. We use non-marking EPDM rubber (Shore A 70-80 durometer) specifically compounded for the glass industry. It provides grip without residue, ensuring your coated glass arrives pristine.

How many empty racks can I fit in a return truck?
Thanks to the nesting design, you can typically fit 3 to 4 times as many empty racks compared to standard rigid A-frames. In a 53ft trailer, this translates to significant freight savings.

Are these racks compatible with vacuum lifters?
Absolutely. The open L-shape design provides unobstructed access to the glass face, allowing vacuum lifters or glass robots to pick sheets easily without interference from vertical retaining bars.

Can you customize the base width for our specific delivery trucks?
Ja. Wir passen die Maße häufig an, um die Nutzung der LKW-Ladefläche zu maximieren. Übliche Anfragen umfassen Längen von 60″ oder 90″ oder spezifische Basisbreiten, um sie nebeneinander auf Flachbetten zu platzieren.
