Heavy Duty Industrial Racking Warehouse Storage Pipe Cantilever Rack

Cantilever rack is also called arm rack, single sided and double sided are both available. Cantilever rack is quite simple structure

Request a quote
Heavy Duty Industrial Racking Warehouse Storage Pipe Cantilever Rack
Overview


Key attributes

Industry-specific attributes

Type
Cantilevered

Material
Steel

Feature
Corrosion Protection

Use
Warehouse Rack

Other attributes

Place of Origin
China

Brand Name
steelpalle

Model Number
cantilever racking

Depth
1.5-3mm

Weight Capacity
500-3500kg

Width
900-3000mm

Height
2000-8000mm

Product name
Heavy Duty Cantilever Racks

Usage
Warehouse Storage

Color
RAL System

Surface treatment
Color Powder Coated

Size
Customer Size

Application
Goods Storage

Packing
Customers' Request

Style
Heavy Duty Selective Shelf

Structure
Knocked-down Structure

MOQ
1 Set

Packaging & delivery

Package Type:
Palletized,Export-Purpose Packaging

Supply Ability

Supply Ability
100000 Set/Sets per Month

View More

Product details



Heavy duty cantilever racking
Cantilever rack is also called arm rack, single sided and double sided are both available. Cantilever rack is quite simple structure, very easy to be assembled and disassembled.It is ideal solution for storage of long objects like metal extrusions,steel bars, tubes, pipes, carpet rolls, lumber and furniture etc.

Product Name
Cantilever racking
Style
Quick access,adjustable
Material
Grade Q235/H-steel
Certification
ISO9001
Standard Color
Blue(RAL5017), Orange(RAL2004), Green(RAL6000), Light Grey (RAL7035), Yellow(RAL1037)
Adjustable Pitch
50mm,50.8mm,76.2mm
Access Style
High accessibility & selectivity
Surface Treatment
Powder Coated or Galvanized
Application Environment
Normal Temperature or Freezer
Design Service
Free CAD service available
Back-up Service
Installation Drawing/On Site Instruction
Lead time
3 weeks for 2*40' container
Standard package
Palletized, Export-Purpose Packaging
Container Load
15-18tons/1*20' container, 20-25tons/1*40' container
Trade Term
EXW/FOB/CNF/CIF

Company Profile

Product drawings
