Heavy duty Sheet Metal Storage Rack System

Cantilever rack Only batch forklift access Drawer type matching mechanization Access is placed near the cutting machine or production machine,More flexible and convenient to use

Request a quote
Heavy duty Sheet Metal Storage Rack System
product description


SHEET RACK BENEFITS



INCREASE
FLOOR SPACE

* Increased Vertical Storage
* Increased Storage Density
* More Storage Per Sq Ft
* Maintain Professional Appearance



SUPERIOR
ORGANIZATION

* Easily & Quickly Locate Materials
* No More Mixed Piles of Material
* Numbered Grid System
* Simplified Inventory Counts



IMPROVED
SAFETY

* No More Drooping Sheets
* Sharp Edges & Corners Not Exposed
* Decreased Tripping Hazards
* Single-Operator Material Handling

Sheet dimensions
Type
Quantity of drawers
Height between drawers
Loading capacity of drawers
2000 x 1000 mm
HSR 200
2 – 15 drawers
50-100-150-235 mm
1000 – 2000 – 2500 – 3000 kg
2500 x 1250 mm
HSR 250
2 – 15 drawers
50-100-150-235 mm
1000 – 2000 – 2500 – 3000 kg
3000 x 1500 mm
HSR 300
2 – 15 drawers
50-100-150-235 mm
1000 – 2000 – 2500 – 3000 kg
4000 x 1500 mm
HSR 400 – 150
2 – 15 drawers
50-100-150-235 mm
1000 – 2000 – 2500 – 3000 kg
4000 x 2000 mm
HSR 400 – 200
2 – 15 drawers
50-100-150-235 mm
1000 – 2000 – 2500 – 3000 kg
6000 x 2000 mm
HSR 600 – 200
2 – 15 drawers
50-100-150-235 mm
1000 – 2000 – 2500 – 3000 kg
6000 x 2500 mm
HSR 600 – 250
2 – 15 drawers
50-100-150-235 mm
1000 – 2000 – 2500 – 3000 kg







Cantilever rack
Only batch forklift access




Drawer type matching mechanization
Access is placed near the cutting machine or production machine,More flexible and convenient to use
it can access plates of different sizes in layers

————————————————————————————————————————————————————————————-

Product Photograph

Product drawings
